More than just a cable
In short: the H1Z2Z2-K 6mm² is no off-the-shelf solution – it’s a specialized energy cable for an industry that doesn’t compromise.
# Technical specifications and construction in detail
One of the strengths of this cable lies in its material structure and the resulting thermal and mechanical durability.
# Technical specifications and construction in detail
One of the strengths of this cable lies in its material structure and the resulting thermal and mechanical durability.
Technical Specifications & Construction
ConductorFine-stranded, tinned copper conductor (Class 5)
Rated voltage1500 V DC (compliant with EN 50618)
Test voltage6.5 kV
Operating temperature range-40 °C to +90 °C (conductor max. +120 °C)
Insulation and sheathCross-linked polyolefin, halogen-free
Outer diameter (6mm²)approx. 6.4 mm
Bending radiusmin. 4 × cable diameter
Max. current capacityup to 70 A (depending on ambient temperature)
Standards and certifications: EN 50618 & more
TÜV 2 PfG 1169/08.2007
CPR classification (Construction Products Regulation)
Conclusion: The comprehensive compliance with standards makes the H1Z2Z2-K 6mm² a reliable and legally secure solution for all professional PV applications.
# Areas of application: Where the H1Z2Z2-K 6mm² shows its strengths
Whether out in the open, in commercial buildings, or integrated into hybrid power plants – this cable delivers reliably.
## Typical fields of application:
- Ground-mounted solar parks
- Industrial rooftops and carports
- Agri-PV systems (e.g. above fields, animal barns)
- Off-grid PV systems
- Inverter connections
- Storage systems and DC networks
# Areas of application: Where the H1Z2Z2-K 6mm² shows its strengths
Whether out in the open, in commercial buildings, or integrated into hybrid power plants – this cable delivers reliably.
## Typical fields of application:
- Ground-mounted solar parks
- Industrial rooftops and carports
- Agri-PV systems (e.g. above fields, animal barns)
- Off-grid PV systems
- Inverter connections
- Storage systems and DC networks
The H1Z2Z2-K also proves its worth in special applications, such as near salty air zones or in environments with extreme temperature fluctuations.
# Underground installation of PV cables – what to consider
One major advantage of the H1Z2Z2-K is its suitability for direct burial – without protective conduit. However, certain rules still apply:
## Best practices for installation:
- Bedding in sand or fine-grained material
- Protection from sharp-edged stones by replacing with gravel
- Installation with minimum spacing from other cables
- Marking with warning tape 30 cm above the cable
- Avoid tensile stress during installation
# Underground installation of PV cables – what to consider
One major advantage of the H1Z2Z2-K is its suitability for direct burial – without protective conduit. However, certain rules still apply:
## Best practices for installation:
- Bedding in sand or fine-grained material
- Protection from sharp-edged stones by replacing with gravel
- Installation with minimum spacing from other cables
- Marking with warning tape 30 cm above the cable
- Avoid tensile stress during installation
